3M9495MP 3M9495B 3M9495FL 200MP Polyester Double Coated Tape

3M9495MP 3M9495B 3M9495FL 200MP Polyester Double Coated Tape

    • 3M9495MP 3M9495B 3M9495FL 200MP Polyester Double Coated Tape
    • 3M9495MP 3M9495B 3M9495FL 200MP Polyester Double Coated Tape
  • 3M9495MP 3M9495B 3M9495FL 200MP Polyester Double Coated Tape

    Product Details:

    Place of Origin: California, United States
    Brand Name: 3M
    Model Number: 3M9495MP 3M9495B 3M9495FL 200MP

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Rolls
    Price: USD 100-800/ Roll
    Packaging Details: Standard carton box packing or Shrink Pack or As Customer's Request
    Delivery Time: Within 7 working days after received the payment
    Payment Terms: T/T,Western Union,Paypal
    Supply Ability: 500 Roll/Rolls per Day
    Contact Now
    Detailed Product Description
    Material: Polyester Adhesive Type: Pressure Sensitive, Modified Acrylic
    Adhesive Side: Double Sided Feature: Waterproof
    Adhesive: Acrylic Use: Masking
    Thickness: 0.13mm

    3M9495MP 3M9495B 3M9495FL 200MP Polyester Double Coated Tape


    3M™ Double Coated Tape 9495MP with 3M™ Laminating Adhesive 200MP features a thin polyester film for dimensional stability and improved handling during die-cutting and laminating. This tape also provides excellent temperature and chemical resistance.

    Features and Benefits
    • Easy handling during slitting and die-cutting
    • Polyester carrier provides dimensional stability
    • Adhesive provides exceptional temperature and chemical resistance and withstands tough application environments



    Product Attributes

    Application Antenna Bonding, Battery Bonding, Electrical Insulation Bonding, Flex Bonding, Flex Stiffener Bonding, Logo Bonding, Touchpad Bracket Assembly, Wire and Cable Clip Attachment
    Application Category Bonding
    Backside Adhesive Thickness 2.3 mil
    Backside Adhesive Thickness (metric) 0.058 mm
    Backside Adhesive Type 200MP Acrylic, Firm Acrylic
    Carrier Color Clear
    Carrier Material Polyester
    Carrier Thickness 0.50 mil
    Carrier Thickness (metric) 0.013 mm
    Faceside Adhesive Thickness 2.9 mil
    Faceside Adhesive Thickness (metric) 0.074 mm
    Faceside Adhesive Type 200MP Acrylic, Firm Acrylic
    Liner Color Tan with 3M 200MP Print
    Liner Thickness 4.0 Milli-inch (mil)
    Liner Thickness (metric) 0.10 mm
    Liner Type Polycoated Kraft
    Operating Temperature Range (Celsius) Long Term (Days-Weeks) 121 Degrees C
    Operating Temperature Range (Celsius) Short Term (Minutes-Hours) 149 Degrees C
    Product Series 9495MP
    Substrate Glass, HSE Plastics, Metals
    Total Tape Thickness without Liner 5.7 mil
    Total Tape Thickness without Liner (metric) 0.14 mm

    3M9495MP 3M9495B 3M9495FL 200MP Polyester Double Coated Tape3M9495MP 3M9495B 3M9495FL 200MP Polyester Double Coated Tape

    We could cut to any roll width according to the customer’s requirement. And we account the price by per square meter.



    If you have interesting of cooperation with us, we could send you some tape samples for testing use. And please give me the address to send the samples.
