| Place of Origin: | California, United States |
| Brand Name: | 3M |
| Model Number: | 3M9690 3m9690B 300MP |
| Minimum Order Quantity: | 1 Rolls |
|---|---|
| Price: | USD 100-1200 / Roll |
| Packaging Details: | Standard carton box packing or Shrink Pack or As Customer's Request |
| Delivery Time: | Within 7 working days after received the payment |
| Payment Terms: | T/T,Western Union,Paypal |
| Supply Ability: | 500 Roll/Rolls per Day |
| Material: | Polyester | Adhesive Type: | Pressure Sensitive, Modified Acrylic |
|---|---|---|---|
| Adhesive Side: | Double Sided | Feature: | Waterproof |
| Adhesive: | Acrylic | Use: | Masking |
| Thickness: | 0.13mm |
| Application | Camera Module Assembly, Foam Bonding, Foam Gasket Bonding, Rubber Feet Bonding, Speaker Module Assembly |
| Application Category | Bonding |
| Backside Adhesive Thickness | 2.3 mil |
| Backside Adhesive Thickness (metric) | 0.058 mm |
| Backside Adhesive Type | 300MP Acrylic |
| Carrier Color | Clear |
| Carrier Material | Polyester |
| Carrier Thickness | 0.50 mil |
| Carrier Thickness (metric) | 0.013 mm |
| Faceside Adhesive Thickness | 2.8 mil |
| Faceside Adhesive Thickness (metric) | 0.071 mm |
| Faceside Adhesive Type | 300MP Acrylic |
| Liner Color | Tan With 3M Print |
| Liner Thickness | 6.2 Milli-inch (mil) |
| Liner Thickness (metric) | 0.16 mm |
| Liner Type | Polycoated Kraft |
| Operating Temperature Range (Celsius) Long Term | (Days-Weeks) 121 Degrees C, (Days-Weeks) 93 Degrees C |
| Operating Temperature Range (Celsius) Short Term | (Minutes-Hours) 149 Degrees C |
| Product Series | 9690 |
| Substrate | Foam, Glass, HSE Plastics, LSE Plastics, Metals |
| Total Tape Thickness without Liner | 5.5 mil |
| Total Tape Thickness without Liner (metric) | 0.14 mm |
We could cut to any roll width according to the customer’s requirement. And we account the price by per square meter.
If you have interesting of cooperation with us, we could send you some tape samples for testing use. And please give me the address to send the samples.
